Electrochemical Work Station (EWS) with Impedance Analyser ad FTAC Voltammeter










Name of the equipment:

Electrochemical Work Station (EWS)



Make & Model:

BAS Inc, CH1660E, Serial No.11177

CS-3A Cell Stand, Serial No.1118



I-Stem Registration ID:

3245531



Category of Instrument

Characterization and Testing



Types of Analysis / Testing:



Application:

Used in fundamental and applied research to gain a proper understanding of electrode processes, analytical chemistry, battery research and corrosion research. Secondary applications include chemical synthesis and biology.



Description of Instrument

It is used to investigate the electrochemical properties of materials and solutions.



Booking Details
seses






Book through I-STEM:

https://www.istem.gov.in/



Slot Booking Link

I-STEM Slot Booking link for External User



Booking available for

Internal and External Both



Requisition form for

Internals

Contact DetailsExternals









Faculty In-charge:

Dr. Mini Mol M.



Email ID:

minimol@nitc.ac.in



Phone number:

+91-7558035591

Technical Staff:

Vinay Kumar (TA) vinaykumar@nitc.ac.in



Features, Working Principle and Specifications

Department

Chemistry



Office Email ID

chyoffice@nitc.ac.in



Location

PG Instrumentation Lab



Lab Phone No

……………………………….









Features of the equipment



ü  Used in both fundamental and aapplied research to gain proper understanding of electrode processes, analytical chemistry battery research and corrosion research. Secondary applications include chemical synthesis and biology.

Unique features/Measurement capabilities, if any

Ø  Control and measures electrochemical potentials and currents.

Instrument Technical Description and Major Specifications (This Specifications Limited to Major 5)



  • Potentiostat/Galvanostat functionality.
  • Electrochemical Impedance Spectroscopy to measure the impedance of a system at different frequencies.
  • Investigating the effects of corrosion on materials.
  • Battery Technology Research.
  • Digital Signal Generator (DSG).


Type of Sample Required for Analysis / Testing (Quantity, Pre-Preparation, State etc.) Guidelines for Sample Submission – User Instructions

Measurement/Sample specifications:

  • Electrode Configuration: 2- or 3-electrode (or 4-electrode if needed).
  • Grounding: Floating (isolated) or earth ground.

  Power Supply: 230VAC, 50Hz as per Indian standard.










·         Quantity: Depends on sample type.

·         Sample Type: Solid and liquid.

·         Pre-preparation: Ensure proper sample preparation to avoid contamination and ensure accurate results.

·         Type of Samples to be Analyzed – Liquid.

·         Maximum No. of Samples Accepted at a Time- 10

·         Minimum No of Days Required for Analysis – 1 week

User Charges Rs. (GST Extra)






Internal

External Academic Institutes

National R&D Lab

Industry

50/- (for each basic analysis)

200/- (for each basic analysis)

200/- (for each basic analysis)

500/- (for each basic analysis)
