Name
of the equipment:
Atomic
Absorption Spectrophotometer
Make
& Model:
Perkin
Elmer PinAAcle 900F
I-Stem
Registration ID-
3222318
Category
of Instrument
●
Advanced
Manufacturing facility
●
Characterization
& Testing
●
Computational
Facility
●
Bioscience
& Technology
● Sample preparation
Types
of Analysis / Testing
●
Elemental
analysis (metals and semi-metals)
●
Quantitative
determination in liquid/solid samples
Application:
●
Heavy
metal detection in water, soil, and industrial waste
●
Food
safety (trace metal contaminants)
●
Pharmaceutical
and chemical industry quality control
● Metal Detection in
Archaeology, Mining, Forensics, Manufacturing etc.
Description of Instrument
A
high-performance flame AA spectrometer with a true double-beam design for
fast startup and long-term stability. Features fiber-optic light throughput
for improved detection limits, an 8-lamp turret, and automated flame
optimization. Controlled by Syngistix™ for AA software for streamlined
workflows, with optional 21 CFR Part 11/EU Annex 11 compliance for
regulated labs.
|
|
|
 |
|
|
 |
|
Features
of the equipment
✔ Double-beam optics
for stability & precision
✔ 8-lamp turret with
automatic alignment
✔ Fiber-optic light
path for enhanced sensitivity
✔ Automated
flame/burner optimization
✔ Syngistix™
software with compliance options
|
Unique features/Measurement
capabilities, if any
⮚
Fast
startup (<10 min) with self-diagnostics
⮚
Detection
limits: Low ppm to sub-ppm range
⮚ TurboCharge nebulizer
for improved uptake
|
|
Instrument
Technical Description and Major Specifications
(This
Specifications Limited to Major 5)
▪
Wavelength
Range: 190–900 nm
▪
Spectral
Bandwidth: 0.2, 0.7, 1.4 nm
▪
Flame
Types: Air-Acetylene / Nitrous Oxide-Acetylene
▪
Burner
Head: 10 cm titanium
▪
Lamp
Mount: 8-position auto-switching
|
Measurement/Sample
specifications:
▪
Sample
State: Liquid (acid-digested)
▪
Volume
Required: 2–5 mL (flame)
▪
Pre-Preparation:
Acid digestion (HNO₃/HCl) for solids
▪
Detection
Elements: Pb, Cd, Cu, Zn, Fe, etc.
|
●
Quantity:
o Minimum 20 mL of liquid
sample per element (filtered through 0.2 μm filter)
o Volume may vary based
on expected concentration
●
Pre-Preparation:
o Samples must be
acid-digested (e.g., HNO₃/HCl) if solid/sludge
o Filtered (0.2 μm)
to remove particulates
o pH-adjusted if
necessary (e.g., for preservation)
●
State:
o Liquid only (aqueous
matrix preferred)
o No organic solvents
without prior consultation
●
Standards
Required for Quantitative Analysis
o Provide certified
standards for each target element.
o Each element &
standard counts as a separate sample (charged accordingly).
o If standards are not
provided, only absorbance values will be reported (no quantification).
●
Sample
Processing
o All samples (standards
+ unknowns) processed using client-provided method.
o Raw data only will be
provided (no advanced data interpretation).
●
Minimum
Sample Requirement
o Batch processing:
Minimum 20 total samples (standards + unknowns) per run.
o Smaller batches may
incur additional charges.
●
Submission
Notes
o Label samples clearly
with element(s) of interest and expected concentration range.
o Hazardous samples
(e.g., HF-containing) require prior approval.
|
Internal
|
External Academic Institutes
|
National R&D Lab
|
Industry
|
|
200/-
per sample per metal
|
400/-
per sample per metal
|
400/-
per sample per metal
|
1000/-
per sample per metal
|
|
