Features
of the equipment
✔ Electro-mechanical
system: No air or hydraulic pressure
✔ Programmable
compaction: Adjustable compaction cycles
✔ Heating and
temperature control: Maintains optimal sample workability
|
Unique features/Measurement
capabilities, if any
⮚ Heating of the
Segment Roller: Temperature control from room to 180°C
⮚ Programmable
Compaction: Compaction cycles based on load or deformation values
⮚ Sample Preparation:
Uniform density and dimensions, with cored or cut off samples for further
testing
|
|
Instrument
Technical Description and Major Specifications (This Specifications Limited
to Major 5)
● Control Unit
(B039-02): Thermoregulator circuit, temperature probe (up to 180°C)
● Sliding Cart
Heating Option (B039-03): Thermoregulated circuit with temperature probe
● Segmented Roller:
Alternated rotation, programmable for specific load or deformation values
|
Measurement/Sample
specifications:
▪
Ability
to produce samples with uniform density and dimensions
▪
Sample
slabs can be cored or cut off to obtain cylinders and beams for various
tests, such as:
o Bending fatigue
o Indirect tensile
o Static and dynamic
creep
o Stiffness
o 4-point tests
|
